HW-M83-LFT1F2N60-0000-000 3-Row Datamate Connectors

Name: HWM83LFT1F2N600000000 3Row Datamate Connectors
Brand: HIGH WOOD
Price: 10 USD

China HW-M83-LFT1F2N60-0000-000 3-Row Datamate Connectors factory

Brand Name : HIGH WOOD

Model Number : HW-M83-LFT1F2N60-0000-000

Certification : AS9001

Place of Origin : China

MOQ : 100PCS

Price : 10＄--150＄

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100,000pcs per month

Delivery Time : 2--9 weeks

Packaging Details : standard export package

Insulation resistance : ≥1000MΩ

Insulator : Glass fiber reinforced PPS

Accessory : Stainless steel

Endurance : 500cycles

Operating temperature : -55 ℃ - 125 ℃

Contact : Copper alloy nickel bottom gold plating

Contact Now

HW-M83-LFT1F2N60-0000-000

M83 3-Row Datamate Connectors offer high reliability with a space-saving design. Available in six standard sizes from 18 to 96 contacts, the 2mm pitch, 3A per contact connectors are ideal for board-to-board or cable-to-board applications where a high number of contacts are required in a small space. The 3-Row Datamate Connectors are available with vertical or horizontal PCB tails and all contacts are gold finish. Applications include Industrial, Medical and Military/Aerospace markets.

Specification:

Materials
- Glass-filled thermoplastic moldings, UL94V-0
- Brass shell female contacts with beryllium copper inner contact
- Phosphor bronze male contacts
- Gold finish
Mechanical
- 500 operation durability
- 1.0N maximum insertion force
- 0.2N minimum withdrawal force

Environmental
- -55°C to +125°C operating temperature range
Electrical
- 2.2A to 3.3A current range
- 800VDC/ACrms working voltage
- 1200VDC/ACrms voltage proof
- 20mΩ to 25mΩ maximum contact resistance

FEATURES

Increased contact count with low insertion force contacts
High levels of shock and vibration
High-reliability applications

Product pictures:

HW-M83-LFT1F2N60-0000-000 3-Row Datamate Connectors
