HW-M55-7106842R 1.27mm (0.05") Pitch PCB Horizontal SMT Connector

Brand Name : HIGH WOOD

Model Number : HW-M55-7106842R

Certification : AS9001

Place of Origin : China

MOQ : 100PCS

Price : 10＄--150＄

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100,000pcs per month

Delivery Time : 2--9 weeks

Packaging Details : standard export package

Connection Type : Surface Mount (SMT)

Connector Orientation : Horizontal

Number of Rows : 2

Number of Signal Contacts : 68

Operating temperature : -55 ℃ - 125 ℃

Current Rating : 1.2A max per contact

Finish / Plating on Contact Surface : Gold

Contact Now

HW-M55-7106842R 1.27mm (0.05") Pitch PCB Horizontal SMT Connector

HW-M55-7106842R

PRODUCT DESCRIPTION

  • Double Row Surface Mount, 10mm total footprint depth, shrouded polarized connector – 68 contacts (34+34). Location pegs, surface mount hold-down retaining tabs for additional solder strength.
  • Board stacking connectors for 90 degree or coplanar board-to-board connection. Supplied in Tape and Reel. Gold finish on contact area, Tin finish on termination.

SPECIFICATION

Contact Pitch:

1.27mm (0.05")

Contact Gender:

Male/Plug

Connector Orientation:

Horizontal

Connection Type:

Surface Mount (SMT)

Current Rating:

1.2A max per contact

Operating Temperature:

-55°C to +125°C

Soldering Data:

Max Solder Temperature: 260°C for 10 seconds

Polarising Features:

Yes

End Stackable:

No

Side Stackable:

No

Can be cut to another size:

No

Number of Rows:

2

Number of Signal Contacts:

68

MATERIALS

Finish / Plating on Termination:

100% Tin over Nickel

Finish / Plating on Contact Surface:

Gold

Base Material of Contact:

Phosphor Bronze

Housing Material:

LCP

Housing Colour:

Black

Housing Material UL Rating:

UL94V-0

Product pictures:

HW-M55-7106842R 1.27mm (0.05") Pitch PCB Horizontal SMT ConnectorHW-M55-7106842R 1.27mm (0.05") Pitch PCB Horizontal SMT ConnectorHW-M55-7106842R 1.27mm (0.05") Pitch PCB Horizontal SMT ConnectorHW-M55-7106842R 1.27mm (0.05") Pitch PCB Horizontal SMT Connector


Product Tags:

HW-M55-7106842R



HW-M55-7106842R SMT Connector



1.27mm Pitch PCB Horizontal Connector


China HW-M55-7106842R 1.27mm (0.05") Pitch PCB Horizontal SMT Connector factory

HW-M55-7106842R 1.27mm (0.05") Pitch PCB Horizontal SMT Connector Images
